BFT Waterjet Parts

BFT Waterjet Parts



Item

Part Number

Description

Item

Part Number

Description

1

CP022002/190

cylinder

22

S24B20/103

snap ring

2

1200402

piston complete

23

XN5/220

initiator

3

XK121/220

piston sealing

24

XST9/220

Plug

4

XF56/220

wear ring

25

CP022009/779

high pressure cylinder

5

CP022066/220

plunger complete

26

CP022010/527

bearing bush

6

CP022057/075

clamp ring

27

CP022011/150

Sealing

7

HT022044/103

retaining ring

28

CP022012/780

Back ring

8

034858/220

o-ring backring 97

29

CP022040/591

quadring

9

XST17/220

rod sealing

30

CP022013/014

distance bushing

10

XF29/220

rod wear ring

31

CP022040/591

Valve body

11

D23M20360/046

cylinder dead screw

32

CP022015/527



back ring



12

CP022017/172

connection flange

33

XF35/220

rod wear ring

13

CP022016/172

connection flange

34

CP022022/591

split ring

14

CP022021/593

thread ring

35

CP022018/563

flange

15

HT022004/473

piston

36

CP022019/563

flange

16

CP020030/562

guide bolt

37

CP022039/563

flange

17

CP020031/473

guide bolt

38

D23M20x65/046

cylinder head screw

18

CP020032/562

supporting ring

39

CP022047/844

pressure valve

19

CP020033/255

helical spring

40

CP022109/844

suction valve

20

CP020034/255

helical spring

41

MA160818/220

swivel male elbow

21

CP020034/255

helical spring

42

OR0759017/151

o-ring 75,92x1,7
